Book Errata

SOLIDWORKS 2024 Advanced Techniques

Mastering Parts, Surfaces, Sheet Metal, SimulationXpress, Top-Down Assemblies, Core & Cavity Molds

Published January 18, 2024
854 Pages
ISBN: 978-1-63057-635-6

Errata

Chapter 5 Page 26

Toward the top of the page, the directions for selecting tangency is partially covered by a figure. The instructions should read as follows:

For Start Constraint, select the Tangency to Face option from the drop-down list. This option applies a constraint to control tangency to the start profile.

Chapter 11 Page 15

The author has updated the helmet surfaces tutorial. This lesson has updated step six to make use of the Loft tool instead of the Sweep tool. An updated version of this exercise and the updated part files are available below.

Updated Helmet Surfaces Tutorial
